Wire Size for a 100-Amp Subpanel 100 Feet Away: A Comprehensive Guide

Choosing the correct wire size for your electrical project is crucial for safety and efficiency. Undersized wires can overheat, leading to fire hazards, while oversized wires are wasteful and unnecessary. This guide focuses specifically on determining the appropriate wire size for a 100-amp subpanel located 100 feet from the main panel. We'll break down the calculations, consider different wire types, and address important safety considerations.

Understanding Voltage Drop and its Importance

Before diving into wire size calculations, it's vital to grasp the concept of voltage drop. Voltage drop is the reduction in voltage as electricity flows through a conductor (your wire). A significant voltage drop can lead to several problems:

• Reduced Power: Appliances and equipment may not operate efficiently or at their full capacity.
• Overheating: Increased current flow due to voltage drop can cause the wire to overheat, posing a fire risk.
• Malfunctioning Equipment: Some sensitive equipment can malfunction due to inconsistent voltage supply.

For a 100-amp subpanel over a long distance like 100 feet, voltage drop is a significant concern that needs careful consideration. We need to choose a wire size that minimizes this drop while adhering to safety regulations.

Calculating Wire Size: The Formula and Factors

Calculating the correct wire size involves several factors, including:

• Amperage (I): The amperage rating of your subpanel (100 amps in this case).
• Voltage (V): The voltage of your electrical system (typically 120V or 240V). We will consider both.
• Distance (L): The one-way distance from the main panel to the subpanel (100 feet in this case). Remember that the total length of wire is twice the one-way distance because the electricity travels to and from the subpanel.
• Wire Material: Copper or aluminum. Copper is more conductive and generally preferred but more expensive.
• Acceptable Voltage Drop: Typically, a maximum voltage drop of 3% is recommended for branch circuits and a maximum of 5% for feeders (like the run to your subpanel).

The formula for calculating voltage drop is:

VD = 2 × I × L × R / 1000

Where:

• VD = Voltage Drop (in volts)
• I = Current (in amps) - 100 Amps
• L = Length (in feet) - 200 feet (100 feet out and 100 feet back)
• R = Resistance of the wire (in ohms per 1000 feet) - This value depends on the wire gauge and material.

We also need to consider the voltage. A common approach is to calculate the voltage drop for both 120V and 240V circuits to ensure sufficient capacity for all loads.

Choosing the Right Wire Gauge: A Step-by-Step Example

Let's walk through an example calculation using copper wire for a 120V system, aiming for a maximum 3% voltage drop. We will then adapt it for 240V and consider aluminum as an alternative.

Step 1: Determine the Acceptable Voltage Drop

For a 120V system, a 3% voltage drop is 3.6V (120V x 0.03 = 3.6V).

Step 2: Rearrange the Formula to Solve for Resistance (R)

We need to rearrange the voltage drop formula to solve for R:

R = (VD × 1000) / (2 × I × L)

Step 3: Substitute the Values

Substituting our values, we get:

R = (3.6V × 1000) / (2 × 100A × 200ft) = 0.09 ohms/1000ft

Step 4: Consult a Wire Resistance Table

Now, we consult a wire resistance table (easily found online) to find the copper wire gauge that offers a resistance of approximately 0.09 ohms per 1000 feet. You'll likely find that a 2/0 AWG (gauge) copper wire comes closest to this value.

Step 5: Repeat for 240V

The process for 240V is the same, except the acceptable voltage drop is now 7.2V (240V x 0.03 = 7.2V). This changes our calculation for R, leading to a potentially smaller wire gauge.

Step 6: Consider Aluminum Wire

Aluminum wire is lighter and cheaper than copper but has higher resistance. We would repeat the calculations above, using the resistance values for aluminum wire from a wire table. Aluminum wire typically requires a larger gauge to achieve the same voltage drop as copper.

Important Safety Considerations

• Ampacity: Always ensure the wire's ampacity rating (the maximum current it can carry continuously without overheating) exceeds the subpanel's amperage rating (100 amps in this case).
• Grounding: The wiring must include a properly sized grounding wire. This is crucial for safety and protection against electrical shocks.
• Overcurrent Protection: The subpanel must have appropriate circuit breakers or fuses to protect against overloads and short circuits.
• Local Electrical Codes: Always adhere to local electrical codes and regulations. These codes specify requirements for wire sizing, installation methods, and safety precautions. Consulting with a qualified electrician is strongly recommended.
• Type of Wire: Select the appropriate type of wire for the environment. For outdoor installations, you'll need weatherproof (e.g., UF-B) wire.
• Proper Installation: Improper installation can negate even the best wire choice. Ensure the wires are properly secured, terminated, and protected.

Beyond the Calculation: Practical Considerations

While the calculations provide a guideline, several practical considerations need attention:

• Future Expansion: Consider potential future increases in electrical load and select a wire gauge that can accommodate that growth. This might require choosing a larger gauge than strictly necessary for the current load.
• Cost vs. Safety: While larger gauges are safer and reduce voltage drop, they also increase cost. Balance cost with the long-term safety and efficiency benefits.
• Aesthetic Considerations: In some cases, the location of the wiring necessitates specific installation methods and cable types.

Professional Consultation: When to Call an Electrician

While this guide provides valuable information, it's crucial to remember that electrical work can be dangerous. If you're not comfortable performing the calculations or installation, always consult a qualified and licensed electrician. They can perform accurate calculations, ensure code compliance, and guarantee a safe and reliable installation. The cost of professional installation is significantly less than the cost of rectifying mistakes or dealing with the potential consequences of an electrical fire.
